CS7.5TM Scissor Lift – Maximum Power for Large-Scale Maintenance

For the most demanding work at height, the CS7.5TM from Custers Hydraulica is the ultimate solution. This vehicle-mounted scissor lift combines a working height of 7.8 meters with an impressive platform capacity of 3,000 kg. Perfect for maintenance tasks in aviation, tunnels, and large-scale infrastructure.

Why choose the CS7.5TM?

• Extremely powerful: Load capacity of 3,000 kg for heavy materials and multiple operators

• Spacious platform: Dimensions of 7.0 x 2.3 m for maximum workspace

• Safe & stable: Robust construction, tilt capacity up to 2° transverse and 5° longitudinal

• User-friendly: PLC control with proportional joystick operation

• Practical design: Access via staircase at the rear of the vehicle

Key Specifications:

• Max. working height*: 7.8 m

• Platform floor height*: 5.8 m

• Platform dimensions: 7.0 x 2.3 m

• Max. load: 3,000 kg

• Min. vehicle weight: 12 t

• Control: Proportional

• Max. tilt: 2° (transverse), 5° (longitudinal)

*Depends on vehicle type, GVW, outrigger construction, platform load, and other factors.
